Articulating hitch
Full-motion articulating hitch for maximum wheel travel and control on rough terrain.
Popular upgrade Mid Range XL · 5′×10′
1,715lbsAs light as built
76″minMinimum height
18″Ground clearance
16″Alloy wheels
Built to go further
Bigger tires. More lift. More trail.
The Mid Range XL takes the balanced Mid Range platform and levels it up — larger 16″ wheels, 32″ tires, a 2″ integrated frame lift, and a reinforced tongue. Built for moderate to heavier off-roading without giving up everyday comfort.
- 3,500 lb torsion axle with 2″ integrated frame lift
- 16″ aluminum alloy wheels · up to 32″ tires
- 18″ ground clearance for rougher trails
- Reinforced tongue · 2″ ball or articulating hitch
The numbers
Mid Range XL model specs
Every Mid Range XL is hand-built to order — here’s the platform it’s built on.
| Specification | 5′ × 9′ | 5′ × 10′ |
|---|---|---|
| GVWR | 2,900 lbs | 2,900 lbs |
| Avg. weight | 1,715 lbs | 1,920 lbs |
| Length | 178″ | 190″ |
| Width | 84″ | 84″ |
| Height | 76″ min | 76″ min |
| Ground clearance | 18″ | 18″ |
| Suspension | 3,500 lb torsion axle w/ 2″ frame lift | |
| Rims | 16″ aluminum alloy | |
| Tires | 235/85/R16 (approx. 32″) or 265/70/R16 (approx. 31.5″) | |
| Lug pattern | 6 on 5.5 or 5 on 5 | |
| Hitch | 2″ ball or full-motion articulating · 7-pin | |
Included on every build
What comes standard
Every Mid Range XL starts fully road-ready — then you customize from there.
- White aluminum exterior
- Solid passenger-side door
- Two side windows w/ screens
- Manual roof vent
- Standard front jack
- 2″ ball hitch
- Safety chains & 7-pin harness
- 110V AC shore power plug
- Rear side swing door
- Two rear galley shelves
- Bottom galley open to cabin
- Middle passthrough doors
- Top passthrough cubbies
- Front USB & volt meter
- Cabin dome light
- Rear galley shelf light
- Rear receiver hitch
- Rear stabilizer jacks
- Stand-on fenders
- Reinforced tongue
- 2″ frame lift
Make it yours
Popular add-on options
Build up from the base to match your terrain, your gear, and your budget. Talk to a trailer expert to spec your exact configuration.
Larger tire & lug options
Choose 32″ or 31.5″ tires and 6 on 5.5 or 5 on 5 lug patterns to match your rig.
Build optionOff-grid power
Battery, solar input, and 12V upgrades to keep your lights and devices running off-grid.
Popular upgrade270° awning
OVS XD Nomadic 270° shade — free with every new build for a limited time.
Included nowGalley & kitchen
Slide-out kitchen, water system, and storage tailored to how you cook on the road.
Build optionClimate & insulation
Insulation, fans, and A/C-ready prep so you’re comfortable in every season.
Build optionOptions shown are representative of Hiker’s build add-ons. Final availability and pricing are confirmed when you configure your build with a trailer expert.
Transparent pricing
Pick your floor plan
Start with the base, then add only what you need. Average-as-built figures come from real 2025 builds.
5′ × 9′
Lighter & more nimble
$11,299 starting
- 1,715 lbs avg. built weight
- 178″ length
- Easier to tow & store
Avg. built · $19,440
Build 5′ × 9′5′ × 10′
Most space & capability
$12,299 starting
- 1,920 lbs avg. built weight
- 190″ length
- Room for longer, rougher trips
Avg. built · $21,286
Build 5′ × 10′
From the road
“The XL’s lift and bigger tires opened up trails our old trailer never could. Still comfortable, way more capable.”
Good to know
Mid Range XL FAQ
How is the XL different from the Mid Range?
The Mid Range XL adds larger 16″ wheels, up to 32″ tires, a 2″ integrated frame lift, a reinforced tongue, and 18″ of ground clearance — built for moderate to heavier off-roading versus the Mid Range’s light-to-moderate range.
What can tow a Mid Range XL?
With a 2,900 lb GVWR and average built weights of 1,715–1,920 lbs, most full-size SUVs and trucks can tow it. Check your vehicle’s rated towing capacity to confirm.
What tire and lug options are there?
You can spec 235/85/R16 (approx. 32″) or 265/70/R16 (approx. 31.5″) tires, with a 6 on 5.5 or 5 on 5 lug pattern to match most foreign and domestic tow vehicles.
How is it built and where?
Every Mid Range XL is hand-built to order in the USA. Because each trailer is custom, your final spec and price are confirmed when you configure your build with a Hiker trailer expert.
Ready to roll
Build your Mid Range XL
Configure your build, choose your options, and get a real quote from a Hiker trailer expert. Custom builds start at $11,299.
